Air |
|
|
1.0Mpa(10.5kgf/cm2) |
|
|
0.7Mpa(7.1kgf/cm2) |
 Lubrication
|
Non-lube
|
|
Piston Speed
|
50-500 mm/s
|
|
Cushion
|
Rubber bumper
|
|
Bore(mm) |
6 mm |
10 mm |
16 mm |
20 mm |
25 mm |
32 mm |
|
|
Working Medium |
Air |
||||||
|
Motion Pattern |
Double action/Single Action Extrusion type/Single Action Drawing-in Type |
||||||
|
Ensured Pressure Resistance |
1.0Mpa(10.5kgf/cm2) |
||||||
| Min. Opetating-pressure | Single | 0.2MPa | 0.15MPa | 0.13MPa | |||
| Double | 0.12MPa | 0.06MPa | 0.05MPa | ||||
|
Max. Working-pressure |
0.7Mpa(7.1kgf/cm2) |
||||||
|
Ambient and Medium Temperature |
Without auto switch:110-70℃ (No freezing) |
||||||
| Lubrication |
Non-lube
|
||||||
| Piston Speed |
50-500 mm/s
|
||||||
| Cushion |
Rubber bumper
|
||||||
|
Rod end thread |
Male thread |
||||||
| Thread tolerance |
Class 2
|
||||||
| Cushion |
Both ends buffer
|
||||||
|
Margin of Stroke Error(mm) |
+1.0 |
||||||
|
Precision of Piston rod with Non-rotating |
±0.8° |
±0.5° |
|||||
|
Port Size |
M5×0.8 |
G1/8" |
|||||
|
Bore size (mm) |
A |
A1 |
B |
C |
D |
E |
GA |
GB |
H |
K |
J |
L |
MM |
|
6 |
7 |
- |
13 |
22 |
3 |
7 |
15 |
10 |
13 |
17 |
10 |
- |
M3×0.5 |
|
10 |
10 |
- |
15 |
24 |
4 |
7 |
16.5 |
10 |
16 |
18 |
11 |
- |
M4×0.7 |
|
16 |
11 |
12.5 |
20 |
32 |
6 |
7 |
16.5Note) |
11.5 |
16 |
25 |
14 |
5 |
M5×0.8 |
|
20 |
12 |
14 |
26 |
40 |
8 |
9 |
19 |
12.5 |
19 |
30 |
16 |
6 |
M6×1.0 |
|
25 |
15.5 |
18 |
32 |
50 |
10 |
10 |
21.5 |
13 |
23 |
38 |
20 |
8 |
M8×1.25 |
|
32 |
19.5 |
22 |
40 |
62 |
12 |
11 |
23 |
12.5 |
27 |
48 |
24 |
10 |
M10×1.25 |
|
Bore size |
NN |
P |
Q |
QA |
R |
T |
Without Auto Switch |
With Auto Switch |
||
|
S |
Z |
S |
Z |
|||||||
|
6 |
M3×0.5(depth) 5 |
3.2 |
- |
- |
7 |
6 (depth) 4.8 |
33 |
46 |
33 |
46 |
|
10 |
M3×0.5(depth) 5 |
3.2 |
- |
- |
9 |
6 (depth) 5 |
36 |
52 |
36 |
52 |
|
16 |
M4×0.7 深(depth) 6 |
4.5 |
4 |
2 |
12 |
7.6 (depth) 6.5 |
30 |
46 |
40 |
56 |
|
20 |
M5×0.8(depth) 8 |
5.5 |
9 |
4.5 |
16 |
9.3 (depth) 8 |
36 |
55 |
46 |
65 |
|
25 |
M5×0.8(depth) 8 |
5.5 |
9 |
4.5 |
20 |
9.3 (depth) 9 |
40 |
63 |
50 |
73 |
|
32 |
M6×1.0(depth) 9 |
6.6 |
13.5 |
4.5 |
24 |
11 (depth) 11.5 |
42 |
69 |
52 |
79 |
|
Bore size(mm) |
A |
A1 |
B |
C |
D |
E |
GA |
GB |
H |
K |
J |
L |
MM |
NN |
P |
|
6 |
7 |
- |
13 |
22 |
3 |
7 |
15 |
10 |
13 |
17 |
10 |
- |
M3×0.5 |
M3×0.5(depth) 5 |
3.2 |
|
10 |
10 |
- |
15 |
24 |
4 |
7 |
16.5 |
10 |
16 |
18 |
11 |
- |
M4×0.7 |
M3×0.5(depth) 5 |
3.2 |
|
16 |
11 |
12.5 |
20 |
32 |
6 |
7 |
16.5 |
11.5 |
16 |
25 |
14 |
5 |
M5×0.8 |
M4×0.7(depth) 6 |
4.5 |
|
20 |
12 |
14 |
26 |
40 |
8 |
9 |
19 |
12.5 |
19 |
30 |
16 |
6 |
M6×1.0 |
M5×0.8(depth) 8 |
5.5 |
|
25 |
15.5 |
18 |
32 |
50 |
10 |
10 |
21.5 |
13 |
23 |
38 |
20 |
8 |
M8×1.25 |
M5×0.8(depth) 8 |
5.5 |
|
32 |
19.5 |
22 |
40 |
62 |
12 |
11 |
23 |
12.5 |
27 |
48 |
24 |
10 |
M10×1.25 |
M6×1.0(depth) 9 |
6.6 |
|
Bore size |
Q |
QA |
R |
T |
V(Note) |
Without Auto Switch |
With Auto Switch |
||||||||||
|
S |
Z |
S |
Z |
||||||||||||||
|
5st |
10st |
15st |
5st |
10st |
15st |
5st |
10st |
15st |
5st |
10st |
15st |
||||||
|
6 |
- |
- |
7 |
6(depth) 4.8 |
- |
38 |
43 |
48 |
56 |
66 |
76 |
38 |
43 |
48 |
56 |
66 |
76 |
|
10 |
- |
- |
9 |
6(depth) 5 |
- |
41 |
46 |
56 |
62 |
72 |
87 |
41 |
46 |
56 |
62 |
72 |
87 |
|
16 |
4 |
2 |
12 |
7.6(depth) 6.5 |
3.5 |
45 |
50 |
60 |
66 |
76 |
91 |
45 |
50 |
60 |
66 |
76 |
91 |
|
20 |
9 |
4.5 |
16 |
9.3(depth) 8 |
5 |
41 |
46 |
56 |
65 |
75 |
90 |
51 |
56 |
66 |
75 |
85 |
100 |
|
25 |
9 |
4.5 |
20 |
9.3(depth) 9 |
5 |
45 |
50 |
60 |
73 |
83 |
98 |
55 |
60 |
70 |
83 |
93 |
108 |
|
32 |
13.5 |
4.5 |
24 |
11(depth) 11.5 |
5 |
47 |
52 |
62 |
79 |
89 |
104 |
57 |
62 |
72 |
89 |
99 |
114 |
